60+60 Watt Stereo Amplifier PCB
This is a 60+60 Watt Stereo Amplifier PCB. It is a high quality, professionally designed printed circuit board for building a powerful dual channel or stereo audio amplifier system at home. This PCB is a perfect choice for audio enthusiasts, electronics hobbyists and professionals who are looking to build your own a high quality stereo amplifier board.
This circuit is designed with a symmetrical layout for left and right channels, the board supports popular power transistor configurations (such as 2SC5200 / 2SA1943 or TIP35 / TIP36 ot TIP3055/TIP2955. This board operates on a dual power supply of voltage +/-27V to +/-35V DC. Use high quality components and a suitable heat sink on it. This amp can deliver up to 60 watts per channel into 4-8 ohm speakers.
The PCB features clearly labelled components, wide copper tracks for high current handling and dedicated pads for speaker output, power supply and audio input. This makes assembly easy and beginner friendly.
Features of 60+60w amplifier PCB Board
- Output Power: 60 + 60W Stereo output.
- Supply Voltage: +/-27V to +/-35V DC
- Transistors used in this PCB : 2SC5200/2SA1943, TIP35/TIP36, 2SC5198/2SA1941, TIP3055/TIP2955
- Low noise and distortion design
- Thick copper tracks for high current
- Clearly marked components and connectors
- Ideal for home audio systems, DIY amplifiers, and speaker projects
Applications
- Home stereo amplifier.
- DIY audio projects.
- Desktop or bookshelf speaker systems.
- Educational electronics projects.
Midhun siva –
I bought this amplifier board from Soldering Mind, and I’m extremely satisfied!
Silent & Powerful: The board is very silent with zero noise/hissing, delivering crystal-clear audio.
Perfect for Beginners: This is the best choice for anyone building their first DIY amplifier. The layout is simple and easy to understand.
Outstanding Support: If you have any doubts during the build, the Soldering Mind team is always ready to clear them. Their customer support is truly helpful.
