Comparison Between TIP35 vs TIP3055

Comparison between tips 35 vs tip 3055 transistors

The “Tip 35” and “Tip 3055” are two types of power transistors used in electronic circuits, but they have some differences. Here’s the detailed comparison between these two types of power transistors.

Share Button

Tip 35 Transistor

  • The TIP35  transistor that allows electric current to flow in one direction.
  • It can handle up to around 40 volts of electrical power.
  • It can handle a current of up to around 25 amps.
  • It can handle several watts of power.
  • It is commonly used in circuits that need high power, like amplifiers and motor controls.

Tip 3055 Transistor

  • The Tip3055 is also allows electric current to flow in one direction.
  • It can handle up to around 60 volts of electrical power.
  • It can handle a current of up to around 15 amps.
  • It can handle several watts of power.
  • It is commonly used in circuits that need medium power, like power supplies and audio amplifiers.

Tip35 vs Tip3055 Transistors

ParameterTip 35Tip 3055
TypeNPN transistorNPN transistor
Max Collector-Base VoltageTypically around 40VTypically around 60V
Max Collector CurrentTypically around 25ATypically around 15A
Power DissipationSeveral wattsSeveral watts
Common UsagePower amplifiers, motor controlPower supplies, audio amplifier
Comparison table of TIP35 vs TIP3055

The Tip 35 is used when you need a lot of power on the circuit, like in amplifiers or motor controls. While the Tip 3055 is used when you need a moderate amount of power, like in power supplies or audio amplifiers. When choosing a transistor, it’s important to check the specifications and consider what your circuit needs that is very important.
