The 1000 watts inverter is based on two-pulse transformers or High-frequency transformer. Previously we discussed 500 watts inverter using pulse transformer. In this post, I would like to share the 1 kW power inverter designs for you. It’s absolutely free for you you don’t need to pay for these designs.
First, you need to understand the workings of this inverter. These high-frequency inverters are not real inverters for converting DC voltage to AC voltage. This inverter will convert 12v DC to 300v DC ( not AC ). so be conscious of that.
CAUTION: The high voltage will make dangerous so do this project carefully
The oscillator ic is sg3535 and the oscillating frequency is about 40khz to 120khz. so you can adjust as per your needs.
Also, you can adjust the output voltage of the transformer through the feedback supply provided to the IC.
To make this project you need to build the inverter driver module first then go for the inverter driver board.
